INO-BOD606 Main Features:



·Individual independent operation of the test cap, optional 1-30 days of testing time, 1-10 hours of constant temperature waiting time, can be individually set sample parameters, each test cap can record 100 historical records, automatically overwrite the old data.

·Bi-directional network communication, wireless interconnection between test cap and host, no delay in data and settings between the two ends of the intercommunication, more stable and reliable communication.

·Support 1-6 samples testing, the host can be a key to open the batch testing, the use of microprocessor control system, automatic completion of the measurement process, no need for personal attention;;

·Range 0-4000mg/L, direct reading of the concentration of detection, without conversion directly display the BOD value, the use of Android system algorithm updates, hardware upgrades to the value of the low range more accurate measurement;

·Test cap is equal to the micro host, using 1.5 inch OLED screen, can run independently, view test data, data graphs and other information, built-in battery short power outages have no effect on the test.

·The host adopts 7-time capacitive screen, real-time display of the test cap power and experimental status, intuitive display of the test data, curve changes, sample naming, etc.: three-screen interconnection of real-time view, host, test cap, cell phone data interoperability, through the cell phone applet to remotely control the experimental process.

·The host can categorize and manage data, and can also filter data by time, keywords, naming, etc., and can compare and analyze the measurement data and historical data curve graphs.



Easy operation, only needs a simple button to complete the setting, in accordance with the volume set in the range of water sample bottle, can complete the test.

Instrument Model	INO-BOD606	Display resolution	0.1mg/L<10mg/L; 1mg/L> 10mg/L
Operating System	LHOS Operating System	Measurement range	(0-4000)mg/L
Pressure measurement accuracy	< ±2.5%	Air tightness	0.1kpa/15min
Measurement accuracy	< ±10%	Frequency of result recording	1 hour
Measurement Period	(1-30) days selectable	Measurement data	Independent 6 groups testing
Bottle capacity	580mL	Stored data	32G
Communication interface	Wireless	Incubation temperature	20±1°C
Rated power	30W	Instrument weight	6.3kg
Instrument size	(306x326x133)mm	Instrument power	30W
Ambient temperature	(5-40)°C	Ambient humidity	85RH (non-condensing)
