Commercial -60℃ Tuna Deep Freezer (Up to -65 ℃)

Commercial -60℃ Tuna Deep Freezer (Up to -65 ℃)
Commercial -60℃ Tuna Deep Freezer (Up to -65 ℃)

Commercial -60℃ Tuna Deep Freezer (Up to -65 ℃)

INNOVA commercial -60℃ Tuna Deep Freezer(Up to -65 ℃)uses an ultra-low temperature cooling system and intelligent temperature control system, combined with the Secop compressor, to lock water for a long time and keep seafood such as tuna fresh. -60℃ deep freezer is also widely used in laboratories, hospitals, materials research and other industries.

FEATURES

1.Technologically advanced refrigeration system

Adopting SECOP compressor,Cascade Cooling refrigeration technology, high efficiency refrigerant mix and Ebmpapst silent fan.

The cabinet cools down faster, more reliable and durable and deeply retains the nutrition and taste of high-end ingredients for a long time.


2.Precise temperature control up to 0.1℃

Touch control microcomputer, precise control of freezing temperature.

Enjoy the freshness of every moment.

The control panel is located in the upper part of the cabinet to facilitate users to observe the real-time operation status of the equipment.

3.Carefully selected materials for high quality

The machine adopts Honeywell Solstice LBA fourth generation environmentally friendly materials, which has better thermal insulation performance and 10% more energy efficiency than traditional thermal insulation materials.

Newly designed automatic air pressure balancing valve makes the door open smoothly and reduces waiting time.

Removable de-icing / can be automatic or manual.

The outer shell parts are made of thickened galvanised steel and adopt electro-static spraying process.

The inner liner is made of high quality 304 stainless steel.Metal handle.

Enhance the anti-corrosion performance of the whole machine from the inside to the outside, and extend the product service life.



4.Simple but extraordinary, easier to clean

Integral shaped sheet metal door body, no wrapped edge cabinet opening design.

Large rounded corners, more simple and friendly.

Reduce dusty corners, easy to clean.




SPECIFICATIONS

ModelMF-60H169 MF-60H269MF-60H369 MF-60H499
ColorCyanGoldLight gray  Light grayLight grayLight gray
Net capacity(L)169269369499
External dimensions W×D×H(mm)940x705x8651150x795x9001460x795x9001870x795x900
Internal dimensions W×D×H(mm)750x410x625960x500x6251270x500x6251680x500x625
Net weight(Kg)7090103126
Voltage/Frequency(V/Hz)220V/50Hz220V/50Hz220V/50Hz220V/50Hz
Power(W)220500500500
Current(A)1.83.23.23.2
Power consumption(KWh/24h)1.652.983.554.85
CompressorEmbraco inverter compressorSECOP inverter compressorSECOP inverter compressorSECOP inverter compressor
Noise dB(A)38555555
Internal materialSUS304
External MaterialSprayed galvanised steel sheet
Evaporator MaterialCopper pipe
Temperature range(℃)-15 to -65℃
Cooling methodDirect cooling
Foam thickness(mm)95
PadlockY
Air pressure balance holeY
CasterY
Compressor protection from high temperature
Y
Alarm buzzer
Y
AlarmSensor failureY
High and low temperatureY
Over ambient temperatureY
